ONKA 6mm2 screw connection terminal block with fuse (fuse not included), gray, 1010241

Terminal block for fuse with threaded connection (the fuse is not included in the package) 2-wire, gray, ONKA, made in Turkey

Used for the protection of low-voltage circuits for alternating or direct current. A fuse with dimensions 5x20 mm is installed in the terminal with a current setting up to 6.3 A. The fuse is not included and must be ordered separately.

Technical parameters

Cross-section of the connected single conductor up to: 6 mm2
Color: gray
Insulation material of the main body: polyamide (PA6.6)
Contact/bridge material: steel/copper CK45
Torque: 0.8 Nm
Connection position: side/side
Cable strip length: 10 mm
Type of electrical connection: screw clamp
Rated voltage: 750 V
Rated current: 6.3 A
Operating temperature range from: -40°C
Operating temperature range to: 140°C
Mounting method: DIN rail mounting 35 mm
Standard: EN-60947-7-1
